- Trajectory
Input: Real-time 6DOF trajectory data from Ethernet port, or stored
files
- User definition
of IMU sensor error model parameters
- Application
Functions: IMU simulation and electronic signal generation, Simulation
accuracy verification, Graphic user interface
- Data format
of Simulated IMU Outputs: RS-232 serial port, user defined format,
RS-422/RS-485 serial port, LAN, USB
- Multiply
selection of result display mode including real-time waveform
and digital format
- Selection
of task control processing, on-line control IMU simulation
- Simulation
IMU Computer Communication Ports: Ethernet local network, RS-232C,
and RS-422/485, USB
- Graphics
Display: Output waveforms for IMU signals
- Dual CPU:
Intel 850 MHz Pentium
- EIDE dual
controller, floppy disk controller
- Dual serial
ports, 16550 compatible, FIFO buffered
- Parallel
port, Bi-directional, EPP and EPC modes
- PS/2 Mouse
port (track ball compatible), keyboard port
- Memory:
256MB SDRAM, expandable on-board to 512 MB
- Bus: Dual
passive backplane
- Display
Interface: Graphics adapter VGA, CRT/LCD simultaneous display
- Internal
Display: Active Matrix TFT LCD, VGA, 800 X 600, 64K color, 10.4
inch
- Keyboard:
Standard 84-key keyboard and 2-button trackball mounted in slide
out tray below computer chassis
- Disk Drives:
Hard drive, 40 Gbytes, fixed, Floppy, 3.5 inch, CD-ROM drive
- Communications:
Ethernet LAN, 100/10BaseT, RS-232, RS-422/RS-485 compatible
- External
15" TFT LCD monitor
- Power supply,
115/230VAC, 50/60Hz
|
